Model

Technical Specifications

Use

YS32-63ZK/40

(1 set)

1 Deep drawing Force:63T

2 Slider stroke:550mm

3 Top cylinder:400KN

4 Drawing stroke:350mm

5 Max.opening height:820mm

6 Effective worktable size:500X500mm

7 Motor power:11KW

8 Machine height:3000mm

9 Machine weight:2500KG

‚1kg second,third drawing.

ƒ2kg third drawing.

YS32-100ZK/50

(1set)

1 Deep drawing Force:100T

2 Slider stroke:800mm

3 Top cylinder:63T

4 Drawing stroke:600mm

5 Max.opening height:1500mm

6 Effective worktable size:720X630mm

7 Motor power:15KW

8 Machine height:4000mm

9 Machine weight:4500KG

4kg third drawing.

‚6kg third drawing.

ƒ9kg third drawing.

④12kg third drawing.

YS32-100ZK/63

(1 set)

1 Deep drawing Force:1T

2 Slider stroke:620mm

3 Top cylinder:63T

4 Drawing stroke:450mm

5 Max.opening height:1100mm

6 Effective worktable size:720X630mm

7 Motor power:15KW

8 Machine height:3600mm

9 Machine weight:4000KG

1kg first drawing.

‚2kg first,second drawing.

ƒ4kg first,second drawing.

④6kg second drawing.

⑤9kg second drawing.

⑥12kg second drawing.

YS32-200ZAK/

100

(1 set)

1 Deep drawing Force:200KN

2 Slider stroke:710mm

3 Top cylinder:1000KN

4 Drawing stroke:350mm

5 Max.opening height:1120mm

6 Effective worktable size:930X900mm

7 Motor power:30KW

8 Machine height:3860mm

9 Machine weight:9000KG

6kg first drawing.

‚9kg first drawing.

ƒ12kg first drawing
